Bioanalytical Systems Laboratory (BASyL)

Contactez-nous

Email
raphael.trouillon@polymtl.ca

Phone
(514) 340-4711 Ext. 5142

Room
M-5029

Facilities

Microscopy and imaging
Fluorescent upright Microscope

Full specifications: Manufacturer's site

Abstract:

  • Working conditions for in vivo brain slice IR-DIC applications
  • Maximum workspace and specimen access designed into the system with special objectives, condensers and optical techniques
  • Platforme fixe, horizontal arm and nosepiece focus for patch clamp stability
  • Filtres: DAPI, GFP, FITC,CY3,CY5,BF
  • Objectifs: 5, 10, 20, 50, 100 x
Axio observer inverted microscope

Full specifications: Manufacturer's site

Cell Culture Microscope

Full specifications: Manufacturer's site

Abstract:

  • Conception pour la culture cellulaire
  • Microscope compact permettant d'être utilisé sous la hotte de culture cellulaire.
  • Objectives: 4, 10, 20, 40 x
Cameras
QImaging Scientific Cameras

Full specifications: Manufacturer's site

Abstract:

  • 1392 x 1040 pixels
  • 4.65µm x 4.65µm pixel size
  • For Brightfield/Darkfield Microscopy
Microfluidics
Microplotter gix-microplotter-ii

Full specifications: Manufacturer's site

Abstract:

  • Feature Size to be plotted: 5-200 µm
  • Uses controlled ultrasonics to deposits fluid in a noncontact manner
UV Flood Curing System intelliray

Full specifications: Manufacturer's site

Abstract:

  • Power:75-150 mW/cm2
  • System Timers:Duration of curing is controlled by a 1 to 9999 second exposure timer that actuates the shutter.
  • Lamp Intensity Control:adjustable intensity level (50%-100%).
  • Status Indicators:Four front panel LEDs are provided: Lamp ready, system in standby mode, shutter open, and system alarm.
Bench Top Profiler contourgt-i

Full specifications: Manufacturer's site

Abstract:

  • To Measure surface features
  • Tip/tilt in the head with automated staging with different objectives
  • Nanometer-scale resolution on high-contour surfaces
  • Real-time automated measurement optimization
Syringe Pump

Full specifications: Manufacturer's site

Abstract:

  • Has 2 independent motors
  • Both motors can infuse, withdraw or infuse and withdraw simultaneously
  • Flow Rate: Min: 0.0004 ul/hr, Max: 106.6 ml/min
Chemistry
Analytical Balance xpe

Full specifications: Manufacturer's site

Abstract:

  • Provide the best performance in analytical weighing and support the highest requirements for safety, efficiency and ease of compliance
  • Max Capacity 120.0 g
  • Min  Weight (USP), Typical  14.0 mg
  • Readability 0.01
Toploading Balance

Full specifications: Manufacturer's site

Abstract:

  • Durable cast-aluminum housing with precision weighing satisfies any laboratory application
  • Max Capacity 210.0 g
  • Readability 0.001
pH/ORP/Temperature Benchtop Meter

Full specifications: Manufacturer's site

Abstract:

  • pH Calibration Check™
  • On-screen electrode condition and response time
  • Up to five point calibration with seven standard buffers
  • Diagnostic alerts through icons
  • Automatic Temperature Compensation
Benchtop Centrifuges

CentrifugeFull specifications: Manufacturer's site

Abstract:

  • Capacity up to 8 x 50mL conical tubes
  • Low noise levels
  • Conforms to the latest clinical and safety standards
Standard Lab Oven

Full specifications: Manufacturer's site

Abstract:

  • Temperature range: 50° to 225°C (122° to 437°F)
  • Adjustable shelf heights
UV/Vis Spectrophotometer

Full specifications: Manufacturer's site

Abstract:

  • Spectral Bandwidth of 3.0 nm
  • Wavelength Range from 190 to 1100 nm
Programmable Digital hotplate stirrer

Full specifications: Manufacturer's site

Abstract:

  • 10-program memory stored in CMOS. No batteries
  • Each program can be 10 steps, where 1 step is a temperature, stirring speed, time, and heating rate
  • Stir up to 4 liters of aqueous solutions from 100 to 1500 rpm
Stirring Hot Plate

Full specifications: Manufacturer's site

Abstract:

  • Max teperature: 540° C
  • Speed: 30-1200 rpm
Adjustable Volume Pipetters

Full specifications : Manufacturer's site

Abstract :

  • Offers a simple set-and-forget lock mechanism to adjust the volume, adjustable finger rest, and proprietary soft touch tip ejection
  • 1000-100 ul, 200-20 ul, 2-20 ul, 0.2-2 ul
  • How to Use a Micropipettor
Pressure/Vacuum Pump

Full specifications: Manufacturer's site

Abstract:

  • Produce maximum gauge pressure of 60psig (413kPag)
  • Vacuum to 25 in. (84kPag)
Mini Ultrasonic Cleaner

Full specifications: Manufacturer's site

Abstract:

  • Ultra Sonic Frequency: 43,000 Hz
  • Tank Capacity: 600 ml
  • To remove grease, dust or other contaminants from surfaces and cavities of small objects, parts and samples
Chemical Hood

Full specifications: Manufacturer's site

Abstract:

  • Benchtop for general chemistry use
  • Alternate Air Usage/Static Pressure at 100 fpm
Ultrapure Water Systems

Full specifications: Manufacturer's site

Abstract:

  • Deliver both pure and ultrapure water directly from tap for use with a wide variety of applications
  • The systems’ built-in 185/254 nm UV lamp reduces the levels of organics for critical applications, and also destroys bacteria
  • Resistivity: 18.2 MΩ·cm at 25°C
Water Bath

Full specifications: Manufacturer's site

Abstract:

  • 5L/10L dual capacity
  • Temp range: Ambient to 100°C
Biological Equipment and Instrumentation
CO2 Incubator

Full specifications: Manufacturer's site

Abstract:

  • Offers precise temperature control and choice of TC (thermal conductivity) or IR (infrared) sensor, as well as a convenient high-temperature decontamination cycle
Biological safety cabinet, ClassII, Type B2

Full specifications: Manufacturer's site

Abstract:

  • For work with non-flammable or explosive volatile chemicals and radionuclides
  • Providing personnel, product, and environmental protection by exhausting 100% of contaminated air
Biological Hood, Class II, Type A2

Full specifications: Manufacturer's site

Abstract:

  • Offeing personnel, product, and environmental protection
  • Obtaining optimum control over product quality while reducing the potential for exposure of both product and personnel to airborne biological or particulate chemical agents in low to moderate risk-hazard research and drug preparation or product operations
Autoclave

Full specifications: Manufacturer's site

Abstract:

  • The 23 liter chamber has compact outer dimensions making it a perfect fit for today’s contemporary clinic.
  • The 23 liter chamber has compact outer dimensions making it a perfect fit for today’s contemporary clinic.
  • The Nova is designed to sterilize class B cycles
Automated Cell Counter

Full specifications: Manufacturer's site

Abstract:

  • Precise volumes are drawn into the Sceptersensor
  • As cells flow through the aperture in the sensor, resistance increases, and, by Ohm’s law (V=IR, where V=voltage, I=current, and R=resistance), this increase in resistance causes a subsequent increase in voltage
  • Voltage changes are recorded as spikes with each passing cell
Misc Items
Farady Cage

Full specifications: Manufacturer's site

Abstract:

  • Shielding Effectiveness: 55 dB at 10 MHz
  • Tested by Independent Electromagnetic Compatibility (EMC) Consultants
Potentiostat

Full specifications: Manufacturer's site

Reservation: Google Calendar

Abstract:

  • VMP-300 is a high-end research grade and fully flexible multipotentiostat
  • Offering 16 slots for potentiostats/galvanostats/FRA boards and/or booster boards
